How it's built

Inside a solar inverter duty transformer.

Two core-coil assemblies in one tank, with the inverter mounted outside. Scroll to take it apart the way it is untanked in a workshop. Prefer a still image? Use “Diagram view”.

Explore our transformers Renewable energy solutions

Request a technical consultation Company portfolio

Inside the machine

Look inside a solar inverter duty transformer.

Two core-coil assemblies in one tank, with the inverter mounted outside. Keep scrolling to take it apart the way it is untanked in a workshop.

01 · Cooling

Radiators come off first.

Pressed-steel radiator banks carry heat out of the oil. Trafo Power manufactures radiators, fin walls and tanks in-house under its Mechanica Elec trademark.

02 · Cover assembly

Lift the cover.

Bushings, tap-changer drive and conservator ride on the cover. Removing it exposes both core-coil assemblies inside the tank.

03 · Untanking

The active part is craned out.

Both core-coil assemblies — one for each inverter section — are lifted clear of the tank on their common frame. The inverter stays on the tank.

04 · Core & windings

Separate the cores and coils.

With the top yokes removed, the low- and high-voltage windings and their insulation slide off the limbs of both cores.

Reassembly

And back together.

Trafo Power's designs are type tested up to 20 MVA, 33/11 kV — temperature-rise, impulse and short-circuit tests at CPRI (Bhopal) or ERDA (Vadodara).

The range

From distribution to power — and the sun.

Distribution, power, solar inverter duty and data center transformers, and the tanks and radiators that go into them.

Explore the range Inverter duty transformers

Illustrative modelSkip

This is an illustrative model, not a specific Trafo Power design. See our real factory
